The 5700MSC-IP is an IP network grandmaster clock and video master sync generator capable of being referenced to GPS and GLONASS global navigation satellite constellations with the included smart antenna, and additionally Galileo and Beidou in L1 and L5 bands with the optional MSC-RF-ADAPT-720 GNSS receiver and MSC-RF-HEAD-720 Dual Band multi-GNSS RF antenna. The system features 2x 1GbE, 2x10GbE ports, 6x independently configurable and fully timeable Sync outputs, 4x SDI video test generator outputs* and a loop-through input. For hybrid plants where LTC outputs, DARS and AES/analog audio test generator signals are required, an optional (+AUX) expansion module is available. This combo IP network grandmaster clock and master sync generator is ideal for timing today's SMPTE 2110 IP-based video broadcast, production and distribution facilities. It provides all the future timing needs of an IP-based plant while providing precision reference to baseband SDI/Analog facilities.
The +SDI-TG test generator option provides several test signals available on the 4x independently configurable SDI (SD/HD/3Gbps) outputs that may be combined to form a 4K UHD test signal generator capable with 2sI or Square Division format.
The +10G-TG test generator option** includes the above SDI test generator feature and adds 6x independently configurable SMPTE 2110 IP outputs in HD and 3G format with SMPTE 2022-7 capability delivering 3 sets of test signals. The +10G-TG option** also supports 4K UHD in 2sI or Square Division by combining four outputs.
As for IP timing formats, the 5700MSC-IP has been designed to be enterprise class, with 4x independently configurable IP timing interfaces (2x 10GbE** and 2x1GbE) for unmatched flexibility and robustness. The architect may now design fault-tolerant meshed timing systems capable of recovering from single points of network failure without resorting to failing over to a degraded grandmaster. PTP profiles include SMPTE 2059-2, AES67 and IEEE1588 Annex J. NTP is supported on all four IP timing interfaces as well as the dedicated control network interface. PCR is supported on 4x IP timing interfaces for workflows where required.
The 5700MSC-IP is delivered with a GNSS smart antenna/receiver (GPS and GLONASS capable) complete with a 50ft cable for remote mounting (100ft, 200ft, 400ft, 800ft, 1200ft and fiber optic extension options are available for longer cable lengths).
A high stability, oven controlled oscillator provides the 5700MSC-IP with better than 1.0x10-8 (or 0.01ppm) frequency reference. The free running drift of this 10MHz reference will be less than 0.1Hz (which amounts to less than one millisecond time drift per day). This guarantees that any frequency drift, with time and temperature will be within the tolerances expected from the best SPGs or master clocks available in the industry.
The SPG section of the 5700MSC-IP provides 6x independent timeable reference outputs. These six sync outputs may be configured to provide independently timed color black (black burst) outputs, independently timed HDTV tri-level sync outputs, 10MHz outputs, word clock, and other bespoke continuous wave signals. Available with a main processing board and optional redundant power supply.
* +SDITG SDI video test signal generator option required
** Optional single-mode and multi-mode 10GbE SFPs not included.
