The following are featured DH Antennas. ATCi carries the full line of DH Parabolic Antennas and products.
3.7M Az/Ei, C/Ku Rx-Only, Fixed Gibralter Mount Antenna
• C-Band Gain - 4 GHz / 42.3 dB
• Ku-Band Gain - 12 GHz / .51.1 dB
• Beamwidth -3 degrees db 4 GHz / 1.4 degrees
• Beamwidth -3 degrees db 12 GHz / .48 degrees
• Isolation Port - Port db / 35
• Antenna Characteristics Weight Raw / 207 pounds
• Size Pre-Spun / 148 inches
• Size Post-Spun / 142.25 inches
• Depth / 20.5 inches
• Area / 113 sq. ft.
• Focal Length - F/D Ratio / 57.6 inches -.4
• Wind Load Survival / 125 mph
• Operational - 4GHz / 75 mph
• Operational at 12GHz / 60 mph
3.7M Az/Ei, C/Ku Rx-Only, Motorized Gibralter Mount Antenna w/ Controller
• C-Band Gain - 4 GHz / 42.3 dB
• Ku-Band Gain - 12 GHz / 51.1 dB
• Beamwidth -3 degrees db 4 GHz / 1.4 degrees
• Beamwidth -3 degrees db 12 GHz / .48 degrees
• Isolation Port - Port db / 35
• Antenna Characteristics Weight Raw / 207 pounds
• Size Pre-Spun / 148 inches
• Size Post-Spun / 142.25 inches
• Depth / 20.5 inches
• Area / 113 sq. ft.
• Focal Length - F/D Ratio / 57.6 inches -.4
• Wind Load Survival / 125 mph
• Operational - 4GHz / 75 mph
• Operational at 12GHz / 60 mph
4.5M AZ/Ei, C/Ku Rx-Only Fixed Gibralter Mount Antenna w/Controller
• C-Band Gain - 4 GHz / 43.9 dB
• Ku-Band Gain - 12 GHz / 53.3 dB
• Beamwidth -3 degrees db 4 GHz / 1.1 degrees
• Beamwidth -3 degrees db 12 GHz / .35 degrees
• Isolation Port - Port db / 35
• Antenna Characteristics Weight Raw / 277 pounds
• Size Pre-Spun / 180 inches
• Size Post-Spun / 176 inches
• Depth / 325 inches
• Area / 171 sq. ft.
• Focal Length - F/D Ratio / 57.6 inches -.33
• Wind Load Survival / 125 mph
• Operational - 4GHz / 65 mph
• Operational at 12GHz / 55 mph
3.7M Az/Ei, C/Ku Rx-Only, Fixed Gibralter Mount Antenna
• C-Band Gain - 4 GHz / 42.3 dB
• Ku-Band Gain - 12 GHz / .51.1 dB
• Beamwidth -3 degrees db 4 GHz / 1.4 degrees
• Beamwidth -3 degrees db 12 GHz / .48 degrees
• Isolation Port - Port db / 35
• Antenna Characteristics Weight Raw / 207 pounds
• Size Pre-Spun / 148 inches
• Size Post-Spun / 142.25 inches
• Depth / 20.5 inches
• Area / 113 sq. ft.
• Focal Length - F/D Ratio / 57.6 inches -.4
• Wind Load Survival / 125 mph
• Operational - 4GHz / 75 mph
• Operational at 12GHz / 60 mph
3.7M Az/Ei, C/Ku Rx-Only, Motorized Gibralter Mount Antenna w/ Controller
• C-Band Gain - 4 GHz / 42.3 dB
• Ku-Band Gain - 12 GHz / 51.1 dB
• Beamwidth -3 degrees db 4 GHz / 1.4 degrees
• Beamwidth -3 degrees db 12 GHz / .48 degrees
• Isolation Port - Port db / 35
• Antenna Characteristics Weight Raw / 207 pounds
• Size Pre-Spun / 148 inches
• Size Post-Spun / 142.25 inches
• Depth / 20.5 inches
• Area / 113 sq. ft.
• Focal Length - F/D Ratio / 57.6 inches -.4
• Wind Load Survival / 125 mph
• Operational - 4GHz / 75 mph
• Operational at 12GHz / 60 mph
4.5M AZ/Ei, C/Ku Rx-Only Fixed Gibralter Mount Antenna w/Controller
• C-Band Gain - 4 GHz / 43.9 dB
• Ku-Band Gain - 12 GHz / 53.3 dB
• Beamwidth -3 degrees db 4 GHz / 1.1 degrees
• Beamwidth -3 degrees db 12 GHz / .35 degrees
• Isolation Port - Port db / 35
• Antenna Characteristics Weight Raw / 277 pounds
• Size Pre-Spun / 180 inches
• Size Post-Spun / 176 inches
• Depth / 325 inches
• Area / 171 sq. ft.
• Focal Length - F/D Ratio / 57.6 inches -.33
• Wind Load Survival / 125 mph
• Operational - 4GHz / 65 mph
• Operational at 12GHz / 55 mph
